TAIWAN PMILINEAR GUIDES
FIVE AXIS CNC
FIVE AXIS SERVO MOTOR
FEATURES
Wire Tension & Cutting Accuracy
Double Direction Wire Tension System (Patent Right) – Optimal wire tension in both directions, reducing breakage and ensuring stable, accurate cuts.
Automated Molybdenum Wire Tension Control – Maintains precise tension, auto-releases during shutdown to extend wire life.
Automatic Wire Loading– Loads wire to preset tension automatically.
Taper (U,V Axis) Brass WEDM Taper Structure – Precision taper cutting for intricate angled cuts.
Wide Taper Cutting Capability – ±12° taper range for versatile applications.
Four-Axis Pitch Error Compensation (X, Y, U, V) – Eliminates cumulative positioning errors.
Motion & Drive System
- Five-Axis Servo Direct Mechanism – Fast and precise control.
- Taiwan PMI Linear Guides – Smooth and long-lasting motion.
- Five-Axis Ball Screws – High repeatability and accuracy.
- Panasonic Servo Motors (XY Axis) – Powerful and precise.
- Z-Axis Motor with Braking Function – Safe and stable vertical movement.
Machine Bed & Structural Design
- Optimized Machine Bed Structure – Verified by Ansys FEA for rigidity and low error.
- Robust T-shaped Bed and Frame Structure– High-grade 250 gray cast iron, aged for stability.
Control & Programming
Autocut (10.1) Programming and Control System:
Five-Axis Pitch Error Compensation.
Reverse Pitch Compensation.
Z-Axis Electric Lifting with Memory.
Intuitive interface for full process control.
Thermal Management
Thermal Cycle Pump (Patented Technology) – Fanless cooling reduces dust, saves energy, and extends lifespan.
Safety & Protection Systems
Multiple Safety Protections:
Digital, Electronic, and Mechanical Limits.
Tension in Place Protection.
Drum Stroke Protection.
Comprehensive Basic Protection:
Automatic Shutdown for Broken Wire.
Short Circuit Rollback.
Power Failure Memory.
Automatic Alarm for Wire Break/Short Circuit.
Wire Spool Edge Stop Protection.
Operator Convenience
User-Friendly Power Supply Blocks – V-groove design for easy wire hanging.
Fully Enclosed Splash Guard & LED Light – Clean, safe, and well-lit work area.
Guide Wire Nozzle – Accurate wire alignment.
Portable Control Boxes – Flexible operation positioning.
Maintenance & Reliability
Efficient Filtration System – 150L dual-pump tank for clean dielectric fluid.
Automatic Oil Pump – Continuous lubrication for long life.
Industrial-Grade Computing & Control – Durable hardware with Dell monitors.
