F-Type Servo Wire Cut Machine PE - Series

Products Details

F-Type Servo Wire Cut Machine PE - Series

AUTOCUT is an advanced wire-cut EDM control system with intelligent automation, ISO/CAD compatibility, and 4-axis precision. It ensures faster cutting, lower consumable costs, and reliable, low-maintenance operation with smart protection and energy-efficient design

Download Brochure
Machine Specs
HF 320PE
FEATURES HF 320
Worktable Size (MM) 690×458
Worktable Stroke (MM) 320×450
Max Cutting Thickness 350
Max Taper Angle ±6°
Max Load Weight (KG) up to 600
Net Weight (KG) up to 1400
Machine Size (XY) 1600×1340×1700
Cutting Accuracy up to ±0.01 MM
Roughness Multiple Cuts Ra up to 1.0um
Max Cutting Speed up to 220 mm²/min
Wire Diameter Standard 0.18 mm
Input Voltage Three-Phase AC 380V 50Hz
Input Power ≤0.8 kW
Book a Visit to Our Experience Centre
HF 400PE
FEATURES HF 400
Worktable Size (MM) 820×568
Worktable Stroke (MM) 450×550
Max Cutting Thickness 350
Max Taper Angle ±6°
Max Load Weight (KG) up to 800
Net Weight (KG) up to 1800
Machine Size (MM) 1650×1600×1700
Cutting Accuracy up to ±0.01 MM
Roughness Multiple Cuts Ra up to 1.0um
Max Cutting Speed up to 220 mm²/min
Wire Diameter Standard 0.18 mm
Input Voltage Three-Phase AC 380V 50Hz
Input Power ≤0.8 kW
Book a Visit to Our Experience Centre
HF 500PE
FEATURES HF 500S
Worktable Size (MM) 910×588
Worktable Stroke (MM) 500×630
Max Cutting Thickness 350
Max Taper Angle ±6°
Max Load Weight (KG) up to 1000
Net Weight (KG) up to 2000
Machine Size (MM) 1700×1720×1700
Cutting Accuracy up to ±0.01 MM
Roughness Multiple Cuts Ra up to 1.0um
Max Cutting Speed up to 220 mm²/min
Wire Diameter Standard 0.18 mm
Input Voltage Three-Phase AC 380V 50Hz
Input Power ≤0.8 kW
Book a Visit to Our Experience Centre
HF 500PE
FEATURES HF 500E
Worktable Size (MM) 1134×712
Worktable Stroke (MM) 500×800
Max Cutting Thickness 600
Max Taper Angle ±6°
Max Load Weight (KG) up to 1200
Net Weight (KG) up to 2600
Machine Size (MM) 2050×2174×2100
Cutting Accuracy up to ±0.01 MM
Roughness Multiple Cuts Ra up to 1.0um
Max Cutting Speed up to 220 mm²/min
Wire Diameter Standard 0.18 mm
Input Voltage Three-Phase AC 380V 50Hz
Input Power ≤0.8 kW
Book a Visit to Our Experience Centre
HF 630PE
FEATURES HF 630
Worktable Size (MM) 1134×850
Worktable Stroke (MM) 630×800
Max Cutting Thickness 600
Max Taper Angle ±6°
Max Load Weight (KG) up to 1400
Net Weight (KG) up to 3200
Machine Size (MM) 2150×2150×2150
Cutting Accuracy up to ±0.01 MM
Roughness Multiple Cuts Ra up to 1.0um
Max Cutting Speed up to 220 mm²/min
Wire Diameter Standard 0.18 mm
Input Voltage Three-Phase AC 380V 50Hz
Input Power ≤0.8 kW
Book a Visit to Our Experience Centre
HF 800PE
FEATURES HF 800
Worktable Size (MM) 1343×850
Worktable Stroke (MM) 800×1000
Max Cutting Thickness 600
Max Taper Angle ±6°
Max Load Weight (KG) up to 1800
Net Weight (KG) up to 3700
Machine Size (MM) 2300×2500×2500
Cutting Accuracy up to ±0.01 MM
Roughness Multiple Cuts Ra up to 1.0um
Max Cutting Speed up to 220 mm²/min
Wire Diameter Standard 0.18 mm
Input Voltage Three-Phase AC 380V 50Hz
Input Power ≤0.8 kW
Book a Visit to Our Experience Centre
HF 1000PE
FEATURES HF 1000
Worktable Size (MM) 1550×1140
Worktable Stroke (MM) 1000×1200
Max Cutting Thickness 600
Max Taper Angle ±6°
Max Load Weight (KG) up to 2100
Net Weight (KG) up to 4500
Machine Size (MM) 2700×2500×2200
Cutting Accuracy up to ±0.01 MM
Roughness Multiple Cuts Ra up to 1.0um
Max Cutting Speed up to 220 mm²/min
Wire Diameter Standard 0.18 mm
Input Voltage Three-Phase AC 380V 50Hz
Input Power ≤0.8 kW
Book a Visit to Our Experience Centre
